830nm-1064nm半导体激光器单模窄线宽激光器IPS
IPS专业研发的波长稳定型激光器可以被理想的应用于：
—— 拉曼光谱
—— 光纤激光器种子源&泵浦源
—— 医学传感&成像
—— 国防基础应用
830nm 单模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成带通滤波器 | 集成光电二极管 | 产品资料 |
| I0830S50100B |
<100 kHz | 100 |
Open Beam |
Yes |
No | TO-56 Data sheet.pdf |
| I0830SB0100B |
<100 kHz |
100 |
Open Beam |
Yes |
Yes |
14-pin Data Sheet.pdf |
| I0830SB0050P |
<100 kHz |
50 |
Unterminated PM Fiber |
No |
Yes |
14-pin Data Sheet.pdf |
| I0830SB0050PA |
50 |
PM Fiber with FC/APC |
No |
Yes |
-- | |
| I0830SB0050S |
50 |
Unterminated SM Fiber |
No |
Yes |
-- | |
| I0830SB0050SA |
50 |
SM Fiber with FC/APC |
No |
Yes |
-- | |
| I0830SD0100B |
<100MHz, <0.2 pm, <0.005 cm-1 |
100 |
Open Beam |
Yes - Dual Filter Pack |
Linear Tracking Photodiode |
D-Type Data Sheet.pdf |
| I0830SU0050PA |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
Single Mode PM Fiber, Panda type with FC/APC connector |
No |
Yes |
U-Type Data Sheet.pdf |
| I0830SU0050SA |
50 |
Single Mode Fiber with FC/APC connector |
No |
Yes |
-- | |
| I0830SR0100B |
<100MHz, <0.2 pm, <0.005 cm-1 |
100 |
Open Beam |
Yes |
Yes |
R-Type Module.pdf |
| I0830SL0050PA |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
Single Mode PM Fiber, Panda type with FC/APC connector |
No |
Yes |
L-Type Module Data Sheet.pdf |
| I0830SL0050SA |
50 |
Single Mode Fiber with FC/APC connector |
No |
Yes |
-- |
830nm 多模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成带通滤波器 | 集成光电二极管 | 产品资料 |
| I0830MB0500B |
<0.15 | 500 |
Open Beam |
Yes |
Yes | 14-pin Data Sheet.pdf |
| I0830MB0350M |
<0.15 |
350 |
Unterminated |
No |
Yes |
14-pin Data Sheet.pdf |
| I0830MB0350MF |
350 |
FC/PC |
No |
Yes |
-- |
|
| I0830MB0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I0830MB0350M-NL |
<0.07 |
350 |
Unterminated |
No |
Yes |
-- |
| I0830MB0350MF-NL |
350 |
FC/PC |
No |
Yes |
-- | |
| I0830MB0350MS-NL |
350 |
SMA905 |
No |
Yes |
-- | |
| I0830MB0600M |
<0.15 |
600 |
Unterminated |
No |
Yes |
-- |
| I0830MB0600MF |
600 |
FC/PC |
No |
Yes |
-- | |
| I0830MB0600MS |
600 |
SMA905 |
No |
Yes |
-- | |
| I0830MU0350MF |
<0.15 |
350 |
FC/PC |
No |
Yes |
U-Type Data Sheet.pdf |
| I0830MU0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I0830MU0350MF-NL |
<0.07 |
350 |
FC/PC |
No |
Yes |
-- |
| I0830MU0350MS-NL |
350 |
SMA905 |
No |
Yes |
-- | |
| I0830MU0500MF |
<0.15 |
500 |
FC/PC |
No |
Yes |
-- |
| I0830MU0500MS |
500 |
SMA905 |
No |
Yes |
-- | |
| I0830MM0350MF |
<0.15 |
350 |
FC/PC |
No |
Yes |
M-Type Data Sheet.pdf |
| I0830MM0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I0830MM0500MF |
500 |
FC/PC |
No |
Yes |
-- | |
| I0830MM0500MS |
500 |
SMA905 |
No |
Yes |
-- |
976nm 单模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置 | 链接器 | 集成光电二极管 | 产品资料 |
| I0976SB0400B |
<100 kHz | 400 |
Open Beam |
N/A |
Yes | 14-pin Data Sheet.pdf |
| I0976SB0750B |
750 |
Open Beam |
N/A |
Yes |
-- |
|
| I0976SB0220P |
<100 kHz |
220 |
PM Fiber, Panda type |
Unterminated |
Yes |
14-pin Data Sheet.pdf |
| 220 |
FC/APC |
Yes |
-- | |||
| 500 |
Unterminated |
Yes |
-- | |||
| 500 |
FC/APC |
Yes |
-- | |||
| I0976SU0220SA |
<100MHz, <0.2 pm, <0.005 cm-1 |
220 |
Single Mode Fiber |
FC/APC |
Yes |
U-type Data Sheet.pdf |
| I0976SU0220PA |
220 |
PM Fiber, Panda type |
FC/APC |
Yes |
-- | |
| I0976SU0500SA |
500 |
Single Mode Fiber |
FC/APC |
Yes |
-- | |
| I0976SU0500PA |
500 |
PM Fiber, Panda type |
FC/APC |
Yes |
-- | |
| I0976SR0400B |
<100MHz, <0.2 pm, <0.005 cm-1 |
400 |
Open Beam |
N/A |
Yes |
R-type Module.pdf |
| I0976SR0750B |
750 |
Open Beam |
N/A |
Yes |
-- | |
| I0976SL0220SA |
<100MHz, <0.2 pm, <0.005 cm-1 |
220 |
Single Mode Fiber |
FC/APC |
Yes |
L-type Module Data Sheet.pdf |
| I0976SL0220PA |
220 |
PM Fiber, Panda type |
FC/APC |
Yes |
-- | |
| I0976SL0500SA |
500 |
Single Mode Fiber |
FC/APC |
Yes |
-- | |
| I0976SL0500PA |
500 |
PM Fiber, Panda type |
FC/APC |
Yes |
-- | |
| I0976SL0400B-TH |
<100MHz, <0.2 pm, <0.005 cm-1 |
400 |
Open Beam |
N/A |
Yes |
Tethered Head H-type Data Sheet.pdf |
| I0976SL0750B-TH |
750 |
Open Beam |
N/A |
Yes |
-- |
976nm 多模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置 | 链接器 | 集成光电二极管 | 产品资料 |
I0976MB4000M I0976MB4000MF or I0976MB4000MS |
<0.15 | 4000 |
105 micron core Multi-mode Fiber (62.5 micron core available upon request, but it will affect output power) |
Unterminated, FC/PC, SMA905 |
Yes | 14-pin Data Sheet.pdf |
I0976MB6000M I0976MB6000MF or I0976MB6000MS |
1053nm单模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成拉曼滤波器 | 集成光电二极管 | 产品资料 |
| I1053SB0050P-IS |
<100kHz |
50 |
PM Fiber/None |
No |
Yes | 14-pin Data Sheet.pdf |
| I1053SB0050PA-IS |
50 |
PM Fiber/FC/APC |
No |
Yes |
-- |
|
| I1053SB0100P |
100 |
PM Fiber/None |
No |
Yes |
-- | |
| I1053SB0100PA |
100 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1053SB0300P |
300 |
PM Fiber/None |
No |
Yes |
-- | |
| I1053SB0300PA |
300 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1053SD0100B |
<100MHz, <0.2 pm, <0.005 cm-1 |
100 |
Open Beam/N/A |
Yes - Dual Filter Pack |
Linear Tracking Photodiode |
D-type Data Sheet.pdf |
| I1053SU0050PA-IS |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
PM Fiber/FC/APC |
No |
Yes |
U-type Data Sheet.pdf |
| I1053SU0100PA |
100 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SU0300PA |
300 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1053SL0050PA-IS |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
PM Fiber/FC/APC |
No |
Yes |
L-type Module Data Sheet.pdf |
| I1053SL0100PA |
100 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1053SL0300PA |
300 |
PM Fiber/FC/APC |
No |
Yes |
-- |
830nm-1064nm半导体激光器单模窄线宽激光器IPS
1064nm单模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成拉曼滤波器 | 集成光电二极管 | 产品资料 |
| I1064SB0500B |
<100kHz | 150 |
Open Beam |
Yes |
Yes | TO-56 Data sheet.pdf |
| I1064SB0050P-IS |
500 |
Open Beam |
Yes |
No |
14-pin Data Sheet.pdf |
|
| I1064SB0050PA-IS |
50 |
PM Fiber/None |
No |
Yes |
14-pin Data Sheet.pdf |
|
| I1064SB0120P |
50 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SB0120PA |
120 |
PM Fiber/None |
No |
Yes |
-- | |
| I1064SB0300P |
120 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SB0300PA |
300 |
PM Fiber/None |
No |
Yes |
-- | |
| I1064SD0150B |
300 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SU0050PA-IS |
<100MHz, <0.2 pm, <0.005 cm-1 |
150 |
Open Beam/N/A |
Yes - Dual Filter Pack |
Linear Tracking Photodiode |
D-type Data Sheet.pdf |
| I1064SU0120PA |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
PM Fiber/FC/APC |
No |
Yes |
U-type Data Sheet.pdf |
| I1064SU0300PA |
120 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SL0050PA-IS |
<100MHz, <0.2 pm, <0.005 cm-1 |
50 |
PM Fiber/FC/APC |
No |
Yes |
L-type Module Data Sheet.pdf |
| I1064SL0120PA |
120 |
PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064SL0300PA |
300 |
PM Fiber/FC/APC |
No |
Yes |
-- |
1064nm多模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成拉曼滤波器 | 集成光电二极管 | 产品资料 |
| I1064MB0800B |
<0.15 |
800 |
Open Beam |
Yes |
Yes |
14-pin Data Sheet.pdf |
| I1064MB0350M |
<0.15 |
350 |
Unterminated |
No |
Yes |
14-pin Data Sheet.pdf |
| I1064MB0350MF |
350 |
FC/PC |
No |
Yes |
-- | |
| I1064MB0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I1064MB0350M-NL |
<0.07 |
350 |
Unterminated |
No |
Yes |
-- |
| I1064MB0350MF-NL |
350 |
FC/PC |
No |
Yes |
-- | |
| I1064MB0350MS-NL |
350 |
SMA905 |
No |
Yes |
-- | |
| I1064MB0600M |
<0.15 |
600 |
Unterminated |
No |
Yes |
-- |
| I1064MB0600MF |
600 |
FC/PC |
No |
Yes |
-- | |
| I1064MB0600MS |
600 |
SMA905 |
No |
Yes |
-- | |
| I1064MU0350MF |
<0.15 |
350 |
FC/PC |
No |
Yes |
U-type Data Sheet.pdf |
| I1064MU0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I1064MU0350MF-NL |
<0.07 |
350 |
FC/PC |
No |
Yes |
-- |
| I1064MU0350MS-NL |
350 |
SMA905 |
No |
Yes |
-- | |
| I1064MU0500MF |
<0.15 |
500 |
FC/PC |
No |
Yes |
-- |
| I1064MU0500MS |
500 |
SMA905 |
No |
Yes |
-- | |
| I1064MM0350MF |
<0.15 |
350 |
FC/PC |
No |
Yes |
M-type Data Sheet.pdf |
| I1064MM0350MS |
350 |
SMA905 |
No |
Yes |
-- | |
| I1064MM0500MF |
500 |
FC/PC |
No |
Yes |
-- | |
| I1064MM0500MS |
500 |
SMA905 |
No |
Yes |
-- |
1064.x nm 多模激光器
| Product ID |
光谱线宽 | 输出功率 (mW) |
输出配置/连接器 | 集成拉曼滤波器 | 集成光电二极管 | 产品资料 |
| I1064.XSB0050P-IS |
<100kHz |
50 |
PM Fiber/None |
No |
Yes |
14-pin Data Sheet.pdf |
| I1064.XSB0050PA-IS |
50 | PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064.XSB0120P |
120 | PM Fiber/None |
No |
Yes |
-- | |
| I1064.XSB0120PA |
120 | PM Fiber/FC/APC |
No |
Yes |
-- | |
| I1064.XSB0300P |
300 | PM Fiber/None |
No |
Yes |
-- |
|
| I1064.XSB0300PA |
300 | PM Fiber/FC/APC |
No |
Yes |
-- |
